Commercial Lifts
Discovery
If your business or commercial build isn't yet wheelchair accessible, the Discovery is a perfect, NCC compliant alternative to installing a long and expensive ramp. Designed to be installed against a landing or verandah externally, the Discovery is also suitable for internal installation to help negotiate split-level builds.
Overview
- Maximum Travel:
- 2m
- Weight Capacity:
- Up to 400kg
- Rated Speed:
- 0.08m/s
- Compliance:
- AS1735.15/EN 81-41, NCC & DDA requirements
- Control:
- Constant Pressure Operation
- Installation:
- Internal and External
- Power Supply:
- 230V Single Phase
- Door Configuration:
- Left or right swing, through car or adjacent entry
- Pit Depth:
- 50mm for flush entry, or ramp provided
Safety Features
The Discovery VPL is engineered in Sweden with an advanced, multi-layered safety suite designed to protect passengers in every situation. Key safety features include:
Manual Lowering — Allows the lift to be safely lowered to the nearest landing during a power loss or system fault.
In-Car Emergency Telephone — Provides direct communication from the lift car to request assistance when needed.
Safety Underpan — Stops the lift immediately if an obstruction is detected beneath the platform.
Emergency Backup Lowering System (Optional) — Automatically lowers the lift to a safe level during a power outage.
Warranty and Maintenance
- 3-year conditional warranty covering both labour and parts.
- Servicing required every 6-12 months to maintain warranty and optimal performance.
- All replacement parts are stocked locally for fast turnaround and minimal downtime.
Engineered For Your Space
